Side Tilt Carriage - There are 4 sizings of hook type fork carriages rated by the blade carriage lifting capacity. Hook type tine carriages have been consistent.
Class I carriages are rated for cargo up to 2000 lbs. The carriage bar spacing for Class I is 13 inches. Class II carriages are rated for cargo as much as 5,550 lbs. Their carriage bar spacing is 16 inches. Class III carriages are rated for loads up to 10,000 lbs. The carriage bar spacing for this class is twenty inches. Class IV carriages are rated for loads up to 15,500 lbs. The carriage bar spacing used for this capacity is 25 inches.
The carriages for pin type blades may be different depending on the maker. Pin mounted tines can differ by the amount of offset between the blade eye and the blade. Carriage capacity would be established by the carriage pin size and by the blade size.
